| Model # | Input Voltage | Input Current | Input Wattage | PF | THD | Output Voltage | Output Current |
| U3-25840D1 | 120-277V | 0.10 - 0.22 A | 25W | > 0.98 | < 20% | 21 - 33 Vdc | 840mA DC |
| U3-35700D1 | 120-277V | 0.15 - 0.35 A | 35W | > 0.98 | < 20% | 28 - 50 Vdc | 700mA DC |
| U3-381050D1 | 120-277V | 0.15 - 0.37 A | 38W | > 0.98 | < 20% | 21 - 36 Vdc | 1050mA DC |
| U3-501400D1 | 120-277V | 0.19 - 0.48 A | 50W | > 0.98 | < 20% | 21 - 36 Vdc | 1400mA DC |
- Line Voltage：120-277 Vac 50/60Hz
- High Power Factor, Low THD
- Standby Power < 1.9 W
- Starting Time < 0.5 sec.
- Constant Current Output
- Open Current Protection
- Short Circuit Protection / Auto Recovery
- Leading or Trailing Edge Phase Control
- Compatible with 0-10V Dimmer
- Efficiency > 88%
- RoHS Compliant
- UL / cUL Listed, Class 2
- FCC Part 15 Class B
- Max Output Voltage : 50V
- Tc max: 85℃
- Ta: -25℃ - 50℃
- No PCB's
- Sound Rated：A
- Dimension: L=6.00" W=1.78" H=1.08"
- Mounting Holes Center: 5.75"
- 5 Years Limited Warranty
